SPS AU-100

SPS AU-100

SPS Ultra 900 is a high-speed ALU ALU & ALU PVC Flat forming-Flat sealing Blister Packing Machine with forming station and sealing station in one single line. The system is provided with a control panel consisting of AC Drive PLC with HMI, SMPS, Vibrator controller, Potentiometer, sensors for product level and Main ON/OFF switches. The system is also provided with Pneumatic controls consisting of Solenoid Valve, Vibrator cylinder, main motor brake cylinder & solenoid coil.

Specifications#

Technical

Max speed
: 10-15 buckets/minute
Weight of Machine
: 700 kg
Machine size (L X H X W) in mm
: (2075 X 2650 X 941)mm

Utilities

Connected Load
: 5 Amps
Power Supply Specification
: Single Phase, 230V
Air Inlet Pressure
: 6-7 bar
Air Consumption
: 10 CFM

Description*

The product is manually charged into the base hopper and is transferred to the Polypropylene buckets through a vibrator mechanism and the product level is controlled by sensors & timer to avoid overflow.

The PP bucket with product is intermittently moved by a chain driven mechanism & the product is discharged into the hopper. The bucket movement is controlled by level sensor in the product hopper.

Machine Construction

Main machine constructed in stainless steel, housing various stations like

  • Vibrator controller tray
  • S.S Machine body
  • Base hopper
  • Elevator buckets driving chain.
  • Machine base

Individually mounted control panel housing all controls Incorporating:

  • Main motor
  • AC Drive
  • PLC with HMI
  • SMPS
  • Vibrator controller
  • Potentiometer
  • Sensors
  • Main ON/OFF switch

Individually mounted Pneumatically housing all controls Incorporating:

  • Solenoid Valve
  • Vibrator cylinder
  • Main motor brake cylinder
  • Solenoid coil
