SPS 2504

SPS 2504

The SPS 2504 is a fully automatic thermoforming (Alu/PVC) Machine which is specifically designed for the production of Pharmaceuticals grade Alu / Pvc blisters. It works in the basic principle of Form, Fill, Inspection ,Seal, Punch and Discharge

Features*

  • This machine is capable of producing Alu/Pvc blisters (PVDC can also run) by forming the pockets, automatically fills them, seals the filled pockets, punches the desired shape from the web and places the punched blisters for onward secondary packing through a transfer tray/ conveyor.
  • The machine is guaranteed to perform and operate as per the given quality output. The command and control parameters are omnipresent throughout the entire production cycle.
  • The production capacity rating of the machine is entirely dependent upon the product, physical parameters and is best denoted by the accompanying layout, which is specific to the product.
  • All the operational controls and sequences of the machine are arranged by Human- Machine-Interface mounted conveniently located in front of the machine on swivel arms assisted by gasolift and a rotary encoder, which determines the positional accuracy of the machine with the feedback.
  • This operator panel includes Human Machine Interface; start stop and emergency stop keys and phase indicating lamps.
  • All parametric changes can be effected with controls through the Human-Machine- Interface, which has multiple levels of password protection. The program is extremely operator friendly and can be easily implemented by your machine operator on short duration training from experts at Schnell Pack. The HMI displays current spilt second information and dynamic positioning of the machine.
  • The machine requires very minimal or no tools to de-clamp or clamp the various format parts that you intend to use on the machine.
  • Voltage monitoring relay to stop the machine in case of any voltage variations, which will avoid major hardware damage.

Specifications#

Technical

Maximum punching speed
: 120 punches/min (product specific)
Maximum forming speed
: 60 cycles/min (product specific)
Maximum forming area
: 230X140 mm
Maximum base foil width
: 230 mm
Maximum lidding foil width
: 226 mm
Maximum forming depth
: 12 mm

Utilities

Connected Load
: 18 KW
Average power consumption
: 10 KW
Cooling water consumption
: 200-250 Ltr/hr
Compressed air
: 15 CFM
Net weight
: 1500 Kg (Approx.)

Machine Dimensions

Machine Length
: 3200 mm
Machine Width
: 950 mm
Machine Height
: 1800 mm

Flooring Dimensions

Length
: 5400 mm + 2%
Width
: 3500 mm + 2%
Height
: 2400 mm + 2%

Packaging Material Specification*

Base Foil

PVC opaque/ transparent(thermo formable), non toxic PVC with PVDC/ Tri laminate

Lidding Foil

110 Aluminum (hard) tempered with heat-sealable coating or Glassine Paper with heat sealable coating.

Description*

Introducing the SPS 2504, a cutting-edge fully automatic thermoforming (Alu/PVC) Machine tailored specifically for the production of Pharmaceuticals grade Alu/PVC blisters. With its innovative features and advanced functionality, this machine revolutionizes blister packaging, ensuring impeccable quality and efficiency throughout the entire production process.

Experience the power of the SPS 2504 as it seamlessly executes the fundamental steps of Forming, Filling, Inspecting, Sealing, Punching, and Discharging. Crafted to perfection, this machine effortlessly produces Alu/PVC blisters, and it can also accommodate PVDC, opening up a world of possibilities for your packaging needs.

With the SPS 2504, precision is guaranteed. The command and control parameters are meticulously integrated into every aspect of the production cycle, ensuring consistent and reliable performance. Say goodbye to operational uncertainties and welcome a seamless production experience.

Featuring an intuitive Human-Machine Interface, the SPS 2504 empowers your operators to take full control. The conveniently located interface, complete with start, stop, and emergency buttons, offers a user-friendly experience. The interface provides real-time information and dynamic positioning of the machine, giving your operators the confidence to optimize productivity.

Our commitment to operator convenience is unmatched. The HMI allows for parametric changes with multiple levels of password-protected access, ensuring security and ease of implementation. Your machine operator will quickly master the program through our comprehensive training, provided by our team of experts at Schnell Pack.

No more time wasted on complex tool adjustments. The SPS 2504 requires minimal to no tools for clamping or de-clamping the various format parts, streamlining your production process and reducing downtime.

We prioritize the safety of your machine and the longevity of its hardware. The SPS 2504 is equipped with a voltage monitoring relay that detects any voltage variations, promptly stopping the machine to prevent potential damage.
